× Ezviz X5S 8W High Performance Wireless NVR

Description

• Specifications
  Model	CS-X5S-R100-8W
  IPC Access Capability
  Wireless/Wired IPC Access Capability	3K *4/3K *8
  Wired IPC Access Capability	3K *4 ‘X5S-4W’ / 3K *8 ‘X5S-8W’
  Network Parameters
  Antenna Number	2
  Max Wireless Range	100m
  Radio Frequency	2.4G
  Ethernet Port	One 10/100M adaptable Ethernet interface
  Required Access Bandwidth	50 Mbps/100 Mbps
  Video Output
  VGA	1 channel ‘identical to HDMI output’ resolution up to 1920*1080/60Hz
  HDMI	1 channel resolution up to 2592*1944/30HZ
  Audio/Video Codec
  Recording Resolution	3K / 2K+ / 2K / 1080p / UXGA / 720p / VGA / 4CIF / 2CIF / CIF / QCIF
  Video Encoding	H.265, H.264
  Decode Playback	Supports 4*3K/Supports 8*3K
  Video Recording Management
  Video Recording Mode	Manual video recording; Motion detection recording; Scheduled video recording; Event triggered recording
  Backup Mode	Hard disk backup, Internet application backup
  Playback Mode	Instant playback ; Normal playback ; Event playback ; Tag playback; Log event playback
  Open Protocol
  Open Protocol Support	HIKVISION, ONVIF ‘V.2.5’
  HDD
  Interface Type	One built-in SATA port
  Capability	Supports 1TB to 8TB 3.5-inch HDD
  External Interface
  Audio Input/ Output	Not support
  Hardware Reset	Supports
  USB2.0 Interface	2
  Dimensions
  Product Dimensions	235 × 270 × 44.5 mm ‘9.25 × 10.6 × 1.75 inch’
  Packaging Dimensions	387 × 362 × 75 mm ‘15.2 × 14.3 × 3 inch’
  Power Supply
  DC	12V/1.5A
  Consumption
  Standby status	≤8W
  Weight
  Net Weight	932 g
  In the box
  In the box	– X5S NVR × 1
  	– Power Adapter × 1
  	– Mouse × 1
  	– Screw Kit × 1
  	– Regulatory Information × 2
  	– Quick Start Guide × 1
  Certifications
  Certifications	CE / UL / RoHS / WEEE / REACH
